MAINTENANCE/ADJUSTMENT
BUCKET HEIGHT CONTROL MINOR ADJUSTMENT 1. Park the machine on a level surface. Lower the loader bucket to the floor. 2. Apply the parking brake and stop the engine. 3. Loosen the rear actuator. 4. To increase the dump height, move the actuator down in the slot. To decrease the dump height, move the actuator up. 5. Tighten the actuator. 6. Start the engine and pull the lift control lever to the RAISE detent position. When the loader arms stop moving, check the dump height.
