OPERATING PROCEDURES (Cont’d)
A
Operating On Slopes
TRAVELING DOWN OR BACKING UP SLOPES
AVOID INJURY OR DEATH • Do not travel across or up slopes which are
over 15 degrees to the side, or to the back of machine or 25 degrees to the front. Keep boom centered while traveling. • Keep attachments as low as possible when traveling on slopes or in rough conditions.
MC–01878B
W–2199–0595
B
TRAVELING ON SIDE SLOPES
TRAVELING UP SLOPES
15 °Maximum
15° Maximum
When going down a slope, control the speed with the steering levers and the speed control lever.
Operate as slow as possible and avoid sudden changes in lever direction. Avoid traveling over objects (such as rocks, trees, stumps, etc.). Stop the machine travel before moving the upper equipment controls. Never allow the blade to strike a solid object. Damage to the blade or hydraulic cylinder can result. When working on a slope, it is recommended to level the work area [C]. If this is not possible, the following procedures should be used:
Dealer Copy -- Not for Resale
When going down grades that exceed 15 degrees, put the machine in the position shown, and run the engine slowly .
MC–01878C
C
RECOMMENDED POSITION FOR WORKING ON A SLOPE
Do not work on slopes which are over 15 degrees. Slow down the work cycle. Avoid working with the tracks across the slope as this reduces stability and increases the tendency for the machine to slide. Position the excavator with the blade down hill and lowered.
MC–01865C
Avoid swinging or extending the bucket farther than necessary in a down hill direction. When you must swing the bucket down hill, keep the dipper arm low and skid the bucket downhill. When working with the bucket on the uphill side, keep the bucket as close to the ground as possible. Dump the spoil far enough away from the trench or hole to prevent the possibility of a cave in.
35 of 74
–17–
325 (S/N 511820001–511821999) Excavator Operation & Maintenance Manual
