TRANSPORTING THE EXCAVATOR ON A TRAILER (CONT’D)
Use chain binders to tighten the chains and then safely tie the chain binder levers to prevent loosening.
Fastening
Figure 134
Figure 132
1
P-87269
When on the transport vehicle, loop the chains through the holes in the mounting frame.
Figure 133
Loop the chain (Item 1) [Figure 134] round the bucket link. 1
P-87267
NOTE: A clevis may be used at the chain holes for the chains to be routed through for clearance. Fasten chains to both corners of the blade (Item 1) [Figure 132] and to the tie down loop at the rear of the track frame (Item 1) [Figure 133] to prevent it from moving when going up or down slopes or during sudden stops.
90 92 of 164
E60 Operation & Maintenance Manual
