PRE-STARTING PROCEDURE (CONT’D)
Mirror Adjustment
Control Console
Figure 64
Figure 63
1 P-86251 P-86320
Adjust mirror (Item 1) [Figure 64] (if equipped). Lower the control console [Figure 63]. NOTE: There is a control lock switch in the left console which deactivates the hydraulic control levers (joysticks and traction system) when the control console lock lever is raised. The console must be in the locked down position for the hydraulic control levers (joysticks and traction system) to operate. NOTE: If the control lock switch does not deactivate the control levers when the console lock lever is raised, see your Bobcat dealer for service.
61 63 of 164
E60 Operation & Maintenance Manual
