INSTRUMENTS AND CONSOLES (CONT’D) Function Icons The table below shows the Icons, their function and other important information. REF.
1
2
3
4
5
6
7
8
9
10
11
FUNCTION
ICON / LIGHT
CONDITION
System Voltage
OFF ON
--Warning
DESCRIPTION
Engine Oil Pressure
OFF ON
--Warning
Engine Air Filter
OFF ON
--Warning
Air Intake Heater
OFF ON
-----
Low Fuel
OFF ON
--Warning
Engine Coolant Temperature
OFF ON
--Warning
Two-Speed Travel
OFF ON
-----
Light ON when Two-Speed activated, High Range engaged.
Working Lights
OFF ON
-----
Light ON when working lights ON.
Engine Check
OFF ON
--Warning
Overload Warning
OFF ON
--Warning
Water In Fuel
OFF ON
--Warning
Voltage out of range - Light will be ON when key is turned to the ON position with engine not started, light will go OFF after engine starts. If light is ON with engine running, shut engine OFF immediately an determine cause of problem. Oil pressure low - Light will be ON when key is turned to the ON position with engine not started, light will go OFF after engine starts. If light is ON with engine running, shut engine OFF immediately. If engine is operated with light ON, serious engine damage may occur. Indicates the air filter(s) needs servicing when light is ON.
Air intake heater energized. In cold weather with the key in the ON position, the icon indicates the engine preheat feature is activated. When icon is OFF with the key in the ON position means the engine preheat cycle has finished and the engine can be started. Light ON when fuel in tank is approximately 10 L (2.6 U.S. gal) or less. Add fuel as soon as possible.
Light ON when engine temperature exceeds allowable limit. Alarm will sound and the engine RPM will automatically be reduced. Check engine temperature gauge, if indicator is in red zone on gauge, allow engine to idle until engine temperature reaches white zone. Continue to allow engine to idle for another few minutes. Stop engine and allow to cool before servicing.
Light flashes when engine needs servicing. Stop engine and service as needed. (Light flashes a service code pattern to indicate problem.) When switch is activated - the light ON and alarm sounding indicates the load exceeds the maximum allowable limit (lift capacity exceeded). Reduce load immediately.
Light ON when water in fuel filter is indicated. Drain water from fuel filter as soon as possible.
Figure 10
The right console contains the instrument panel with Function Icons [Figure 10].
1
Engine Coolant Temperature Gauge (Item 1) [Figure 10]. Gauge indicate engine coolant temperature and allowable operating range. WHITE area indicates coolant temperature is in normal operating range. RED area indicates engine coolant temperature is to high. When in RED area, engine rpm will automatically be reduced. Allow engine to idle until engine temperature is in normal operating range. Stop the engine and allow coolant to cool and service as required.
2
3 3
Fuel Level Gauge (item 2) [Figure 10]. Shows amount of fuel in fuel tank. Function Icons information.
P-86955A
37 39 of 164
(Item
3)
[Figure 10],
see
above
E60 Operation & Maintenance Manual
