INSTRUMENT PANEL IDENTIFICATION
Left Console [Figure 8]
Overview
REF. NO.
Figure 7
1 2
3
1
P-86248
Slide the switch (Item 1) [Figure 7] to turn the cab light ON or OFF.
4
Figure 8 5
1
2
6
4
5
P-86215 P-86216
35
FUNCTION / OPERATION
Left Joystick
(See HYDRAULIC CONTROLS on Page 50.) Horn Press lower button on left joystick to sound horn. (Key switch must be in ON position for horn to operate.) (The top two switches on the left joystick are not used for this model.) Air Conditioner / Press A/C button to turn air Fan Motor conditioner ON, Press OFF button to turn A/C OFF and also turns the fan motor OFF. (When the A/C button is pressed to the ON position, the Fan motor speed must also be selected before the A/C will work. When both the A/C button and a fan speed button is pressed, the light above the A/C button will be ON.) Fan Speed Press Low - Medium - High button Select to select fan speed. (Light above button selected will be ON.) Temperature Press COOL button repeatedly to Control / Heater lower temperature / press WARM Activation button repeatedly to raise temperature. There are 24 positions to select the desired temperature range. (Lights above COOL / WARM buttons will show the temperature selected. Green lights indicate cool / red lights indicate warm.)
6
3
37 of 164
DESCRIPTION
Air Vent / Air Flow Location
To activate HEAT, the OFF button must be pressed. Press the desired fan speed button, then repeatedly press the WARM button until the desired temperature is selected. To turn heater OFF, press the OFF button to turn the fan motor to OFF. Press the desired button to control air flow to various areas in the cab. The icons on the buttons indicate the air flow location. (See Heating, Ventilation And Air Conditioning Duct on Page 45.)
