TRACK ROLLER AND IDLER LUBRICATION
LUBRICATING THE EXCAVATOR
Procedure
Lubrication Locations
The track rollers and idlers require no maintenance. The bearings are a sealed design.
Lubricate the excavator as specified in the SERVICE SCHEDULE for the best performance of the machine. (See SERVICE SCHEDULE on Page PM-5) Record the operating hours each time you lubricate the excavator. Always use a good quality lithium based multi-purpose grease when lubricating the excavator. Apply the lubricant until extra grease shows. Figure PM-60
2 3
P-66321
Ref Description (# of Fittings) 1. Blade Cylinder-Rod End, every 8 - 10 hours (1) [Figure PM-60] 2. Blade Pivots, every 8 - 10 hours (2) [Figure PM-60] 3. Blade Cylinder-Base End, every 8 - 10 hours (1) [Figure PM-60]
99 of 136
PM-35
319 Operation & Maintenance Manual
Dealer Copy -- Not for Resale
1
