TRAVEL MOTOR
Removing And Replacing Oil
Checking And Adding Oil
(See SERVICE SCHEDULE on Page PM-5) for the correct service interval.
Figure PM-51 Put the machine on a level surface with the plugs positioned as shown (Items 1 & 2) [Figure PM-51]. Remove the bottom plug (Item 2) and top plug (Item 1) [Figure PM-51] and drain into a container. Recycle or dispose of the used lubricant in an environmentally safe manner. After all the gear lube is removed, install plug (Item 2) [Figure PM-51].
1
Add 0.53 qt. (0,5 L) of SAE-90W gear lube to the plug hole (Item 1) [Figure PM-51] until the gear lube level is at the bottom edge of the plug hole (each motor).
2 P-66337
Install and tighten the plug. Put the machine on a level surface with the plugs positioned as shown (Items 1 & 2) [Figure PM-51].
Dealer Copy -- Not for Resale
Repeat the procedure for the other side.
Remove the plug (Item 1) [Figure PM-51]. The oil level should be at the bottom edge of the plug hole. Add SAE-90W gear lube through the hole if the oil level is below the hole (each motor). Install and tighten both plugs. Repeat the procedure for the other side.
