Removing the LCD Antennas NOTE: These disassembly procedures feature the 3G model only, therefore there are four antenna cables (white, black, yellow, and blue) addressed during the procedure. If 3G is not supported, only the WLAN antennas (white and black) need to be removed. 1. See “Removing the LCD Panel” on page 74. 2. The LCD Module appears as follows when the Camera, Microphone, and LCD Panel are removed. •
A— blue 3G Antenna cable
•
B— combined yellow 3G Antenna cable, white and black WLAN Antenna cables
A
B
3. Remove the adhesive strips holding the cables in place.
Chapter 3
77
