Bottom View
Clearing Password Item
Description
Item
Description
JP5
SIM Card Connector
U6
SB
JP13
FAN Connector
JP7
To Card reader/B Connector
JRJ45
RJ45 LAN Connector
JMINI 1
MINI Card (Wireless) SOCKET
JCRT1
CRT Connector
JDIM1
DDR2 Socket
JUSB1
External USB Connector
U5
CPU
JMIC1
MIC IN Connector
U1
NB
JHP1
Head-Phone Connector
JMINI 2
MINI Card (3G) SOCKET
Clear Password Check and BIOS Recovery For Information on Password Check and BIOS Recovery See “Clearing Password Check and BIOS Recovery” on page 33.
BIOS Recovery by Crisis Disk For Information on Crisis Disk See “BIOS Recovery by Crisis Disk” on page 35.
130
Chapter 5
