Chapter 5
Jumper and Connector Locations Top View
Item
Chapter 5
Description
Item
Description
JLVDS1
LCD Connect Internal camera Connector Internal DMIC Connector
JP2
TO PWR/B Connector
LED4
Bluetooth LED
JP12
Internal Keyboard Connector
SW4
Bluetooth Button
JP11
Internal Track-Pad Connector
LED3
Media LED
SW3
Right Button
LED5
NUM LED
SW2
Left Button
LED6
CAP LED
JP20
Speaker Connector
PJP1
TO Power core Connector
JBT1
Bluetooth Connector
PJP2
Battery Connector
