Removing the Battery Pack 1.
See “Removing the SD Dummy Card” on page 44.
2.
Turn the notebook over so the bottom is facing up.
3.
Slide the battery lock/unlock latch to the unlock position.
Note: Battery has been highlighted with the yellow circle as above image shows. Please detach the battery and follow local regulations for disposal. 4.
Slide the battery release latch to the release position (a) to pop out the battery pack, then remove the battery pack from the main unit (b).
Chapter 3
45
