Hardware Specifications and Configurations Processor Item
Specification
CPU type
Aspire 7736/7336 Series: Intel® Core™2 Duo P8800 PGA (2.66 GHz) Intel® Core™2 Duo T6500 PGA (2.1 GHz) Intel Celeron 900 PGA (2.2 GHz) Aspire 7736Z Series: Intel Pentium Dual-Core T4200 PGA (2.0 GHz) Aspire 7540 Series: AMD Turion II M520 2.3 GHz AMD Athlon II M320 2.1 GHz AMD Turion M620 2.5 GHz
Core logic
Aspire 7736/7736Z/7336 Series: Mobile Intel® PM45/GM45/GL40 Express Chipset Aspire 7540 Series: AMD M880G Chipset
CPU package
Aspire 7736/7736Z/7336 Series: 478-pin micro-FCPGA Aspire 7540 Series: Socket S1
CPU core voltage
Aspire 7736/7736Z/7336 Series:: 1.0375V to 1.3V Aspire 7540 Series: 1.35V to 1.5V
CPU Fan True Value Table DTS(degree C)
Fan Speed (rpm)
Acoustic Level (dBA)
45-50
0-3000
29
55-66
0-3300
33
68-74
3300-3800
38
78-83
3800-4100
40
86-91
4100-4800
40
Throttling 50%: On= 99 C; OFF=93 C OS shut down at 105 C; H/W shot down at 110 .C BIOS Item
Specification
BIOS vendor
Phoenix
BIOS Version
Aspire 7736/7736Z/7336 Series: v1.16 Aspire 7540 Series: v1.07
System Memory Item
Specification
Memory controller
Built-in
Memory size
0MB (no on-board memory)
DIMM socket number
2 sockets
Supports memory size per socket
2048MB
Supports maximum memory size
4GB for 64bit OS (with two 2GB SODIMM)
Supports DIMM type
DDR 2 Synchronous DRAM
Supports DIMM Speed
667 MHz
Supports DIMM voltage
1.5V
Supports DIMM package
240-pin soDIMM
