Main The Main screen allows the user to set the system time and date as well as enable and disable boot option and recovery.
Information
Main
Advanced
PhoenixBIOS Setup Utility Security Boot Exit Item Specific Help
System Time: System Date:
[19:10:59] [12/12/2008]
System Memory: Extended Memory:
634 KB 1790 MB
Quiet Boot: Network Boot: F12 Boot Menu: D2D Recovery: SATA Mode Selection:
[Enabled] [Enabled] [Disabled] [Enabled] [AHCI]
F1 Help Esc Exit
<Tab>, <Shift-Tab>, or <Enter> selects field.
F 5 / F 6 C h a n g e Va l u e s Sub-Menu Enter Select
Select Item Select Menu
F9 F 10
Setup Defaults Save and Exit
NOTE: The screen above is for your reference only. Actual values may differ. The table below describes the parameters in this screen. Settings in boldface are the default and suggested parameter settings. Parameter
Description
Format/Option
System Time
Sets the system time. The hours are displayed with 24hour format.
Format: HH:MM:SS (hour:minute:second)
System Date
Sets the system date.
Format MM/DD/YYYY (month/day/year)
System Memory
This field reports the memory size of the system. Memory size is fixed to 634 KB.
N/A
Extended Memory
This field reports the memory size of the system. Memory size is fixed to 1790 MB.
N/A
Quiet Boot
Displays the logo screen while booting.
Option: Enabled or Disabled
Network Boot
Enables, disables the system boot from LAN (remote server).
Option: Enabled or Disabled
F12 Boot Menu
Enable the Press <F12> to display Boot Menu message during boot.
Option: Enabled or Disabled
D2D Recovery
Enables, disables D2D Recovery function. The function allows the user to create a hidden partition on hard disc drive to store operation system and restore the system to factory defaults.
Option: Enabled or Disabled
SATA Mode Selection
Control the mode in which the SATA controller should operate.
Option: AHCI or IDE
Chapter 2
25
