Aspire 5735 5735Z 5335 Series Laptop Service Guide Manual -PDF DOWNLOAD

Page 55

Remove HDD/BIOS Utility This section provide you with removing HDD/BIOS method: Remove HDD Password: q

If you key in wrong HDD password for three time, “HDD password error code” would display on the screen. See the image below.

q

If you need to solve HDD password locked problem, you can run HDD_PW.EXE

1. Key in “hdd_pw 15494 0” 2. Select “2” 3. Choose one upper-case string

q

Chapter 2

Reboot system and key in “0KJFN42” or “UVEIQ96” to HDD user password.

45
