Removing the WLAN Board Modules

1. See “Removing the Battery Pack” on page 50. 2. See “Removing the Lower Cover” on page 52. 3. Remove the white antenna cable that is taped to the WLAN board module.

NOTE: There are 2 antenna cables connected to the WLAN board module. The Black antenna cable is connected to the MAIN connector and the Gray antenna cable is connected to the AUX connector. 5. Move the antenna away from the WLAN board and remove the one screw (H) on the WLAN board to release the WLAN board.

Step Size (Quantity) Color Torque 1 M2 x L3 (1) Black 1.6 kgf-cm
