Removing the Lower Cover
1. See “Removing the Battery Pack” on page 50. 2. Remove the four captive screws and the six screws (A) on the lower cover.
Step Size (Quantity) Color Torque 1~6 M2.5 x L8 (6) Black 3.0 kgf-cm
1 minute read
1. See “Removing the Battery Pack” on page 50. 2. Remove the four captive screws and the six screws (A) on the lower cover.
Step Size (Quantity) Color Torque 1~6 M2.5 x L8 (6) Black 3.0 kgf-cm
