Removing the Thermal Module 1. See “Removing the Mainboard” on page 80. 2. Turn the Mainboard over and place on a clean surface. 3. Hold the fan cable connector and lift to disconnect from the mainboard.
4. Remove the four screws from the Thermal Module numerically, from 4 to 1.
2
4 1
3
Step Thermal Module
Chapter 3
Size M 2.5*3.2
Quantity
Screw Type
4
83
