Removing the USB Board 1. See “Removing the Upper Cover” on page 67. 2. Open the FFC securing latch and remove the cable from the Mainboard connector.
3. Remove the single screw securing the USB Board to the Lower Cover.
Step USB Board
Size M2.5*3
Quantity
Screw Type
1
4. Remove the USB Board from the Lower Cover.
Chapter 3
77
