Removing the Speaker Module 1. See “Removing the Keyboard” on page 59. 2. Remove the two securing screws from the Speaker Module.
Step Speaker Module
Size M2.5*3
Quantity
Screw Type
2
3. Remove the adhesive tape securing the LCD cables to the Speaker Module.
IMPORTANT: Do not remove the Speaker from the Upper Cover; the Speaker cable is attached to the Mainboard. 4. Rotate the Speaker Module upward, rear edge first to clear the LCD cables, and remove it from the chassis.
