Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the USB diskette drives, the onboard hard disk drive and the DVD drive in the module bay.
Information
Main
PhoenixBIOS Setup Utility Security Boot Exit Item Specific Help
Boot priority order: 1: IDE0: WDC WD5000BEVT-22ZAT0-(S1) 2: IDE1: MATSHITABD-CMB UJ130AS-(S2 3: USB FDD: 4: Network boot: Atheros Boot Agent 5: USB HDD: 6: USB KEY: 7: USB CD/DVD ROM:
F1 Help Es c Exit
Chapter 2
Select Item Select Menu
F5/F6 Enter
C h a n g e Va l u e s Select Sub-Menu
Use < > or < > to select a device, then press <F6> to move it up the List, or <F5> to move it down the list. Press <Esc> to escape the menu.
F9 F10
Setup Defaults Save and Exit
29
