Chapter 5
Jumper and Connector Locations Top View VGA UMA
Discrete
Item
Chapter 5
Description
Item
Description
SW1
ON/OFF Button
U7
VRAM
JP11
Camera Connector
U5
VRAM
JLVDS1
LCD Connector
SW4
Touch Pad Lock Button
JP12
Speaker Connector
SW 2
Touch Pad (left) Button
JP4
Bluetooth Connector
SW 3
Touch Pad (right) Button
161
