Phoenix BIOS Beep Codes Beep Code 1-1-1-3
Post Code 02h
Description Verify Real Mode.
What to Check (Recommended) • Check the processor. • Check the main board.
1-1-2-1
04h
Get CPU type.
• Check the processor. • Check the main board.
1-1-2-3
06h
Initialize system hardware.
• Check the main board.
1-1-3-1
08h
Initialize cache to initial POST values.
• Check the main board.
1-1-3-2
09h
Set in POST flag.
• Check the main board.
1-1-3-3
0Ah
Initialize CPU registers.
• Check the processor. • Check the main board.
1-1-4-1
0Ch
Initialize cache to initial POST values.
• Check the secondary cache. • Check the processor. • Check the main board.
1-1-4-3
0Eh
Initialize I/O.
• Make sure all the cards are securely inserted into the system. • Make sure that there are no physical problems with the main board or internal connections. • Disable all shadowing of expansion adapter ROMs and see if that fixes the problem. • Remove all unnecessary expansion cards (basically, everything but the video card) and see if the problem goes away. If it does, the problem is probably one of the expansion cards you removed. If not, your problem lies elsewhere. Try to isolate the problem by inserting one expansion card at a time back into the system and seeing which on e triggers the problem.
1-2-1-1
10h
Initialize Power Management.
• Check the main board.
1-2-1-2
11h
Load alternate registers with initial POST values.
• Check the main board.
1-2-1-3
12h
Jump to UserPatch0.
• Check the main board.
1-2-2-1
14h
Initialize keyboard controller.
• Check the keyboard. • Check the keyboard controller. • Check the main board.
1-2-2-3
16h
BIOS ROM checksum.
• Check the main board.
1-2-3-1
18h
8254 timer initialization.
• Check the main board.
1-2-3-3
1Ah
8237 DMA controller initialization
• Treat as an expansion card problem.
Chapter 4
• Check the main board.
