Disassembly Procedure Removing the Battery Pack 1. Unlock the battery lock to the end as the arrow indicates. 2. Slide the battery latch to the end and hold it. Then remove the battery pack.
Removing the HDD Module 1. Release the two screws fastening the HDD module cover. 2. Detach the HDD module cover. 3. Release the screw securing the HDD module. 4. Pull the HDD module then lift the HDD module as the arrow indicates.
Chapter 3
68
