Hardware Specification and Configuration Processor Item
Specification
Type
AMD Turion
Feature
• • • •
Power
• Multiple low power states • System Management Mode (SMM) • ACPI compliant, including support for processor performance states
TM
64 X2 dual-core TL-50/TL-52/TL-56/TL-60 processor
AMD 638-pin Lidless Micro PGA package 64-bit integer registers, 48-bit virtual addresses, 40-bit physical addresses Eight new 64-bit integer registers (16 total) Eight new 64-bit SSE registers (16 total)
• AMD PowerNow!TM technology is designed to dynamically switch between multiple low power states based on application performance requirements
System Main Chipset Item
Specification
Core logic
ATi RS485M + ATi SB460
System clock
ICS ICS951462
BIOS ROM
SST 39VF080
KBC
NSPC97551
PCMCIA & IEEE 1394 & Memory card reader
PCI7412ZHK
Super I/O
NSPC87383
IR
Vishay TFU6102F
Audio Codec & Amplifier
Realtek ALC883D Azalia Codec and Amplifier Maxim MAX4411
LAN
Broadcom 5788M
North Bridge Item
44
Specification
Chipset
ATi RS485M
Package
465-pin FCBGA package, 21mm x 21mm
Feature
• 200/400/800/1000MHz HyperTransport interface support • One x 16 graphics interface used by another device • Highly-optimized 128-bit engine, capable of processing multiple pixels per clock • Integrated dual 24-bit LVDS interface • 595Mbps/channel with 85MHz pixel clock rate • External displays (e.g., flat panel, CRT or TV) via a DVO port support • ACPI states S1, S3, S4 and S5 fully supported
Power
1.8V core, 3.3V, 5V CMOS I/O
Chapter 1
