Acer Bluetooth® VoIP Phone Layout #
Item
Description
"Launch keys" on page 10
#
#
20
Icon
Item
Icon
Description
Item
Description
1
N/A
PC Card (PCMCIA) interface connector
Connects the computer’s PCMCIA card interface.
2
N/A
Speaker
Speaker delivers audio output.
3
N/A
Volume up/down button
Increases/decreases the sound volume.
4
Power button
Turns the phone on and off.
5
Bluetooth connection/ Enables/disables the Bluetooth function. pairing button
6
Speakerphone button Enables/disables the speakerphone function.
7
N/A
Microphone
Internal microphone for sound recording.
8
N/A
Flip
Flips out internal microphone.
9
N/A
Bluetooth connection/ Indicates the Bluetooth connection/pairing status. pairing indicator
10
N/A
Charge/Power indicator
Indicates the computer’s charge/power status.
