Conveying Line Components Cam and Groove Couplings
Eight standard couplings pictured Swivel, reducing and special couplings available Materials of construction vary Sizes 5” and 8”-12” are not industry interchangeable Sizes 0.50” 0.75” 1.00” 1.25” 1.50” 2.00” 2.50” 3.00” 4.00” 5.00”
Part A Male Adapters - Female Thread
Part B Female Couplers - Male Thread
Part C Female Couplers - Hose Shank
Part D Female Couplers - Female Thread
Part E Male Adapters - Hose Shank
Part F Male Adapters - Male Thread
Dust Plug For Use with Couplers
Dust Cap For Use with Adapters
