Specifications 2.12 Dimensions model 38Z3 3158
2500
2500
870
2075
4800 Fig. 3:
1740
Machine dimensions (model 38Z3)
Main data Operating weight
Model 38Z3 3630 kg (8003 lbs)
Height
2500 mm (8'-2")
Width
1740 mm (5'-9")
Transport length
4800 mm (15'-9")
Max. digging depth
3110 mm (10'-2")
Stick length (standard)
1500 mm (4'-11")
Stick length (long version)
1750 mm (5'-9")
Max. digging depth for long stick (+ 300 mm)
3360 mm (11'-0")
Max. vertical digging depth
2430 mm (7'-11")
Max. vertical digging depth (long stick)
2670 mm (8'-9")
Max. digging height
4530 mm (14'-10")
Max. digging height (long stick)
4660 mm (15'-3")
Max. dump height
3220 mm (10'-7")
Max. dump height (long stick)
3350 mm (11'-0")
Max. digging radius
5300 mm (17'-5")
Max. digging radius (long stick)
5540 mm (18'-2")
Max. reach at ground level
5300 mm (17'-5")
Max. reach at ground level (long stick)
5430 mm (17'-10")
Max. breakout force at bucket tooth
25.70 kN (5778 lbf)
Max. tearout force (standard stick)
21.90 kN (4923 lbf)
Max. tearout force (long stick)
19.40 kN (4361 lbf)
Min. tail end slewing radius Max. tail end lateral projection over tracks
2-14
1140
300
2725
300
345
870 mm (2'-10") 0 mm (0")
Max. boom displacement to bucket centre (right-hand)
740 mm (2'-5")
Max. boom displacement to bucket centre (left-hand)
590 mm (1'-11")
