Operation 1.15 Raising/lowering the cab Danger! Careful when raising/lowering the cab –
Danger of accidents! ☞ Always tighten screws A, B and C when driving and working with the machine.
☞ Always close the door ☞ Stay clear from underneath the cab as you raise or lower it • Stop the engine • Remove the ignition key • Raise the control lever base (left) Removing the screw Slacken the screws as follows:
☞ Stop the engine ☞ Remove the ignition key ☞ Raise the control lever base (left) ☞ Unscrew screw A with a suitable tool ➥ Screw A is located at the front right in the cab underneath the floor mat ☞ Slacken screw B with a suitable tool ➥ Screw B is located at the right in the cab behind the seat
A
Danger! Always close the door. Even if the door is secured in the open position with the door arrester –
Danger of accidents! B
1-16
☞ Always close the door before raising the cab ☞ Should the door be open as you raise the cab, do not actuate the door opener unintentionally
SHB 38Z3 en – Edition 2.2 * 38z3s110.fm
