Operation 1.7
Cab (legend) Pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
1-8
Designation Hammer pedal Control lever (left) Control lever (right) Control lever base (left) Control lever base (right) Armrest (left) Armrest (right) Lever (horizontal seat adjustment) Rear window air vent Radio (option) Seat (backrest adjustment) Seat belt Cup holder Bracket – document storage bin Console switch panel Cab switch panel Throttle Stabilizer blade lever Fuse box Preheating start switch Cigarette lighter Round indicating instrument Drive pedal (left) Drive pedal (right) Drive lever (left) Drive lever (right) Drive interlock status indicator (option) Front air vent Drive interlock emitter/receiver unit Seat
