Technische Daten 2.11 Vibration Vibration Effective acceleration value for the upper extremities of the body *
< 2.5
m -----s2
(<8.2 ft/s2)
Effective acceleration value for the body *
< 0.5
m -----s2
(<1.6 ft/s2)
*
Measured according to 2002/44/EC. Machine and attachment operation and maintenance as per Operator's Manual.
2.12 Coolant compound table Outside temperature Up to °C (°F) -37 (-34.6)
Coolant: Halvoline XLC (based on ethylene glycol) Eurolub SF D12 coolant (based on ethylene glycol) Water Anticorrosion agent Antifreeze agent cm³/l % by % by volume % by volume volume (in3/gal) 50 10 (2.6) 1 50
Use the 1:1 concentration for warm outside temperatures, too: • Protection against corrosion, cavitation and deposits Do not mix the coolant with other coolants. Coolant with specified features is filled in the machine at the factory. • See “Coolant” label in the engine compartment for information on the coolant used
2-7
SERV-HB 1101c cp EN – Edition 1.0 * *1101c_cp210.fm
