Operation 1.4
Tilting the cab Danger! Careful when tilting the cab –
E
Danger of accidents! ☞ Always tighten lock screws B when driving and working with the machine! ☞ Place the machine on level ground! ☞ Close the door (option)! ☞ Loader unit strut A may only be installed by a second person! ☞ When tilting the cab make sure no-one is underneath the cab! ☞ Loader unit strut A and cab strut C must always be secured with split pin D!
D A
A
Tilting the cab: D E
B
☞ Remove the attachment ☞ Raise the loader unit and have a second person secure it ☞ Remove split pin D from pin E ☞ Remove pin E ☞ Raise the loader unit until strut A makes contact with the piston rod ☞ Put pin E back into place ☞ Secure pin E with split pin D ☞ Switch off the engine ☞ Lower the loader unit down to loader unit strut A ☞ Remove the ignition key ☞ Fold up the safety bars ☞ Remove securing screws B on either side with a suitable tool ☞ Tilt the cab forwards with the handles ☞ Secure the cab with split pin F
F
C Fig. 8:
1-15
Tilting the cab
