Engine body - Service procedures
5
11
Check the axial and the radial clearance of the camshaft. Correct clearance: see Workshop Manual, Technical Data for each engine concerned.
Adjust the valves, and fit the valve covers.
6
12 Fit the remaining equipment. Where necessary top up with lubricant and coolant. Test run the engine.
Check the axial and the radial clearance of the intermediate gear: Correct clearance: see Workshop Manual, Technical Data for each engine concerned. 7 Check the tooth flank clearance. See Workshop Manual, Technical Data for each engine concerned.
Crankshaft, removing (With engine removed)
Special tool: 2655 1 Drain the oil. 2 Remove the oil pan. Remove the oilstrainer and the pressure pipe for the oil pump.
Tooth flank clearance (A)
8 Fit the timing gear cover. See Timing gear cover, assembly. 9 Lubricate the contact surface of the tappets to the camshaft with molybdenum disulphide and oil in the tappets bore in the cylinder block. Install the tappets in the correct order. 10 Install the push rods and rocker mechanism. Engine with cast oil strainer
52
