EVC-C
Powertrim Assistance, PTA D4, D6 (option) The Powertrim Assistant adjust trim angle automatically according to engine speed (rpm). It is possible to set five trim angles at five different engine speeds (Idle speed included).
PTA calibration 1.
Activate helm station by pushing the ACTIVE STATION BUTTON..
Calibration and settings 4.
Select PTA CALIBRATION POSITION (1-5) by turning NAVIGATION WHEEL. Push NAVIGATION WHEEL to enter selected PTA CALIBRATION POSITION..
5.
Set RPM for PTA CALIBRATION POSITION by turning NAVIGATION WHEEL and confirm by pushing NAVIGATION WHEEL.
NOTE! RPM can not be set for PTA CALIBRATION POSITION 1, idling speed.. 6.
2.
Select SETTINGS from MAIN MENU by turning NAVIGATION WHEEL. Push NAVIGATION WHEEL to enter SETTINGS MENU..
3.
Select PTA CALIBRATION and push NAVIGATION WHEEL..
Set TRIM ANGLE for selected PTA CALIBRATION POSITION by turning NAVIGATION WHEEL and confirm by pushing NAVIGATION WHEEL..
Use the same procedure for all PTA CALIBRATION POSITIONs (1-5). Push BACK BUTTON to return to SETTINGS MENU.
Default values for D4 and D6 engines Step
Engine rpm
Drive angle degree
1 2 3 4 5
Idle–2499 - 3. 2500–2999 0. 3000–3199 +1. 3200–3499 +1. 3500–WOT +1
93
