EVC-C
Major components
Cables and cable harnesses, all engines
Y-split multilink, 6-pin Yellow PVC-coating. MULTILINK BREAKOUT
Standard bus cable, 6-pin CONN X2. Green
Part No. Green
MULTILINK. Yellow label
Part No.
MULTILINK. Yellow label
Red
For making branches in the multilink cabling, EVC display–sync. connection–NMEA-connection.
Green Red
The cable must be used to connect the PCU to the HCU.
NOTE! Do not install an Y-split cable without having the MULTILINK BREAKOUT connected. Length, m (ft): 0.5 (1.6)
NOTE! The cable has female connections in both ends and cannot be used as an extension. Two female connectors. Length m: Length ft:
5, 7, 9, 11, 13. 16, 23, 30, 36, 42
Y-connector to 4–20 mA output interface, engine transmission cable, 8 and 12-pin 8-pin connection
0.15 m (0.5 ft) 0.15 m (0.5 ft)
Y-connector, EVC bus cable, 6-pin
8-pin connection
0.20 m (0.7 ft) 12-pin connection
0.25 m (0.8 ft) 0.25 m (0.8 ft) 0.5 m (1.6 ft)
Part No.
To connect the standard bus cable to the HCU in systems with secondary helm stations. Length, m: Length, ft:
0.25 x 0.25 x 0.5 . 0.8 x 0.8 x 1.6
To connect the 4–20 mA interface output to an aftermarket control system supporting 4–20 mA, i.e. a CP-control (pitch) system. The cable is connected to the EMS unit cable . (ENGINE CONN) on the engine/transmission cable harness. This connector is not used on D4 and D6 engines with sterndrive DPH and DPR. Length, m: Length, ft:
0.2 x 2.0 . 0.7 x 6
25
