Electrical systems – 5000 Electrical equipment overview Order number 249896-040
Date 2007-05-11
Valid from serial number 985777-
T-code 789, 790, 791, 817, 818
Table 8: Electrical equipment list summary Symbol
Function
Description
Associated signal names
Inf.
R2
Steering angle signal
Potentiometer
A5:A_IN0 , A_IN1
3
S65
Drive wheel in centre reference
Inductive proximity switch
A5:REF
3
M6
Drive wheel steering
Motor
Steering
3,2
Forks lift R14
Fork lift/ lower control
Hall sensor unit
A2:A_IN
7
Y10
Fork lower -hydraulic control
Proportional magnetic valve
A3:OUT MAGNET VALVE PWM
7,8
B4
Load supervision
Pressure sensor
A3:INP.PRESSURE LIFT
7
M3
Hydraulic pressure
Motor
Support arm lift A2:S19
Support arm lift control
Hall sensor
5,7,8
A2:S20
Support arm lower control
Hall sensor
5,7.8
Y41
Support arm lower -hydraulic control
Magnetic valve
A3:OUT.SUPPORT ARM LOWER VALVE
7,8
Y52
Support arm / fork lift selection
Magnetic valve
A3:OUT. FORK/ SUP.ARM VALVE
7,8
S31
Support arms at top supervision
Inductive proximity switch
A1:INP.SUPPORT ARM AT TOP
7,8 10
S90
Support arms at bottom supervision
Inductive proximity switch
A1:INP.SUPPORT ARM AT BOTTOM
7,8,10
© TIEE SARL
Service Manual
7SLL12.5, 16, 20, 13.5S, 12.5F, 16F, 20F
11- 7
