Chassis – 0000 Engine suspension Order number 249896-040
Date 2007-05-11
Valid from serial number 985777-
T-code 789, 790, 791, 817, 818
5.2 Engine suspension 5.2.1 Components 1 2 3 4
Pos.
Description
1
Axle for torsion tubes
2
Threaded hole
3
Washer
4
Screw
5.2.2 Disassembly Remove the power unit as follows: • Unscrew the four screws (4) holding the power unit in place. • Insert the screws (4) in the threaded holes (2). The torsion tube axles (1) will then be pulled out automatically.
© TIEE SARL
Service Manual
7SLL12.5, 16, 20, 13.5S, 12.5F, 16F, 20F
5- 5
