Electrical systems – 5000 Parameters Order number 249896-040
Date 2007-05-11
Valid from serial number 985777-
T-code 789, 790, 791, 817, 818
11.5.9 Description of service parameters # 10 - PIN code NOTE: On delivery of the truck, the PIN code for driver 1 must be changed to a four-digit code to prevent unauthorised use.
NOTE: The functionality of parameter #10 is ignored if the value of parameter #39 has been set to 5, 6, 7 or 8. PIN code input is facilitated via the extended keypad. For detailed information, see the section Extended keypad - General on page 54.
The parameter stores the truck’s active PIN-codes. The truck can store up to ten PIN-codes. Each PIN-code has a set of parameters associated with it, called driver Parameters. Entering a particular PIN-code at start-up will make the selected PIN-code’s driver parameters active. This allows up to ten operators to individually adjust the characteristics of the truck. On delivery the truck has one default PIN-code stored which is “1“.
To enter a new PIN-code: • Operate [L1] repeatedly in the forward direction to select parameter #10. After one second, the display will show the PIN-code for this driver. • Repeat the step above until parameter#10 for the next driver is displayed, the display will either show PIN-code for that driver OR “0”(zero). • Repeat the step above until the PIN-code displayed is “0”(zero) • Press Horn button [S18]
Parameter symbol flashes.
.
• Operate [L1] to set the desired value of the new PIN-code.1 • Press Horn button [S18]
Parameters symbol lights. (stops flashing). The new PIN-code has now been entered.
1.Operating [L1] lightly will step the value in increments of 1. Operating [L1] fully will step the value in increments of 100 Valid values are 1 to 9999 © TIEE SARL
Service Manual
7SLL12.5, 16, 20, 13.5S, 12.5F, 16F, 20F
11- 45
