11.4.4 Speed limitation The truck’s maximum speed is limited by a combination of, fork lift height, fork load and operator’s driving position. Driver parameter settings also affect maximum speed. See “11.5.6 Summary of driver parameters” on page 41 for more information. The table below summarises the speed limitations and assumes that all relevant driver parameters are set to 100%. Note that the speeds given are nominal.
Table 11: Summary of speed limitations Load (kg)
Fork lift height (mm)
Driver position or mode
Max. speed (km/h)
<800
<1800
Platform down, gates up (transportation mode)
8
Platform down, gates down1
6
Platform up, gates down (pedestrian mode)1
6
Platform up, gates up
0
Platform down, gates up
0
Platform down, gates down1
5
Platform up, gates down (pedestrian mode)1
5
Platform up, gates up
0
Platform down, gates up (transportation mode)
8 - 72
Platform down, gates down1
6
Platform up, gates down (pedestrian mode)1
6
Platform up, gates up
0
Platform down, gates up (transportation mode)
0
Platform down, gates down1
5
Platform up, gates down (pedestrian mode)1
5
Platform up, gates up
0
<800
>800
>800
>1800
<1800
>1800
-
-
Turtle mode is controlled by parameter # 7
-
-
Snail speed mode
≈ 1,6
-
-
Error / Warning code mode
≈ 2,5
1.The 7SLL20 & 7SLL20F do not have side guards; from an electric viewpoint, the side guards are considered to be in the lowered position. 2.Max. speed determined by actual load and will ramp between 8 & 7 km/h
