ENGINE ASSEMBLY < UNIT REMOVAL AND INSTALLATION > 1. Install engine slinger to front cover front left side (A) and cylinder head rear right side (B).
[MR16DDT ]
: Engine front
Slinger bolts Front cover front left side: Cylinder head rear right side: 2. 3.
: 32.9 N·m (3.4 kg-m, 24 ft-lb) : 25.0 N·m (2.6 kg-m, 18 ft-lb)
JPBIA4422ZZ
Remove starter motor. Refer to STR-27, "MR16DDT : Exploded View". Lift with a hoist and separate the engine from the transaxle assembly. Refer to TM-84, "MR16DDT : Exploded View".
INSTALLATION Note the following, and install in the reverse order of removal. CAUTION: • Never allow engine oil to get on engine mounting insulator. Be careful not to damage engine mounting insulator. • Check that each mounting insulator is seated properly, and tighten mounting nuts and bolts. • When installation directions are specified, install parts according to the direction marks on them referring to the figure of components. Refer to EM-55, "2WD : Exploded View". Rear torque rod bracket
1.
Temporarily tighten mounting bolts in the numerical order as shown in the figure. : Vehicle front
2.
Tighten mounting bolts to the specified torque in the numerical order as shown in the figure.
JPBIA4416ZZ
2WD : Inspection
INFOID:0000000006709022
INSPECTION AFTER INSTALLATION Inspection for Leakage The following are procedures for checking fluids leakage, lubricates leakage, and exhaust gases leakage. • Before starting engine, check oil/fluid levels including engine coolant and engine oil. If less than required quantity, fill to the specified level. Refer to MA-13, "Fluids and Lubricants". • Use procedure below to check for fuel leakage. - Turn ignition switch “ON” (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leakage at connection points. - Start engine. With engine speed increased, check again for fuel leakage at connection points. • Run engine to check for unusual noise and vibration. • Warm up engine thoroughly to check there is no leakage of fuel, exhaust gases, or any oil/fluids including engine oil and engine coolant. • Bleed air from lines and hoses of applicable lines, such as in cooling system. • After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to the specified level, if necessary. Summary of the inspection items:
Items Engine coolant
Before starting engine
Engine running
After engine stopped
Level
Leakage
Level
EM-58
