OIL PAN (LOWER) < REMOVAL AND INSTALLATION > b. Apply a continuous bead of liquid gasket (A) with a tube presser (commercial service tool) as shown in the figure. 1
: Oil pan (lower)
b
: 7.5-9.5mm (0.295 - 0.374 in)
c
: φ 4.0 - 5.0 mm (0.157 - 0.197 in)
[MR16DDT ]
: Engine outside
Use Genuine Liquid Gasket or equivalent. CAUTION: Attaching should be done within 5 minutes after liquid gasket application.
JPBIA4367ZZ
c.
Tighten bolts in numerical order as shown in the figure. : Engine front
NOTE: • Tighten bolts the No.1 and No.2 in two steps. • The numerical order No.7 and No.11 shows the second steps.
JPBIA4364GB
2.
3.
Install oil pan drain plug. • Refer to the figure of components of former page for installation direction of drain plug washer. Refer to EM-99, "Exploded View". Install in the reverse order of removal after this step.
Inspection
INFOID:0000000006337265
INSPECTION AFTER REMOVAL Clean oil strainer if any object attached.
INSPECTION AFTER INSTALLATION 1. 2. 3. 4.
Check the engine oil level and adjust engine oil. Refer to LU-8, "Inspection". Start engine, and check there is no leakage of engine oil. Stop engine and wait for 10 minutes. Check the engine oil level again. Refer to LU-8, "Inspection".
EM-42
