INTAKE MANIFOLD [MR16DDT ]
< REMOVAL AND INSTALLATION >
Removal and Installation
INFOID:0000000006337253
A
REMOVAL 1. 2.
Remove engine cover. Refer to EM-25, "Exploded View". EM Pull out oil level gauge. CAUTION: Cover the oil level gauge guide openings to avoid entry of foreign materials. 3. Disconnect turbocharger boost sensor (with intake air temperature sensor 2) harness connector. Refer to C EM-31, "Exploded View". 4. Remove air inlet tube assembly. Refer to EM-31, "Exploded View". D 5. Disconnect water hoses from electric throttle control actuator as follows: • Attach plug to prevent engine coolant leakage when engine coolant is not drained. Refer to CO-11, "Draining". E CAUTION: Perform this step when the engine is cold. NOTE: This step is not required when removing only intake manifold. F 6. Disconnect electric throttle control actuator harness connector. 7. Remove electric throttle control actuator. CAUTION: G • Handle carefully to avoid any shock to electric throttle control actuator. • Never disassemble electric throttle control actuator. 8. Disconnect EVAP canister purge volume control solenoid valve harness connector, and them remove H bracket with EVAP canister purge volume control solenoid valve. 9. Remove vacuum gallery. 10. Disconnect PCV hose (intake manifold side). I 11. Remove intake manifold (1) with the following procedure. • Loosen and remove intake manifold mounting bolt (A). J
K
L JPBIA4385ZZ
• Loosen mounting bolts in reverse order as shown in the figure.
M
: Engine front
NOTE: Disregard the numerical order No.6 in removal. CAUTION: Cover engine openings to avoid entry of foreign materials.
N
O
JPBIA4356ZZ
INSTALLATION Note the following, and install in the reverse order of removal. Intake Manifold
1. 2.
Check if gasket is not dropped from the installation groove of intake manifold. Install intake manifold with the following procedure:
EM-29
