AIR CLEANER AND AIR DUCT < REMOVAL AND INSTALLATION > 7. Remove air cleaner cover assembly. 8. Remove mass air flow sensor from air cleaner cover, if necessary. CAUTION: Handle the mass air flow sensor with following cares. • Never shock the mass air flow sensor. • Never disassemble the mass air flow sensor. • Never touch the sensor of the mass air flow sensor. 9. Remove air duct with resonator with the following procedure. a. Remove fender protector (LH). Refer to EXT-22, "Exploded View". b. Remove air duct with resonator.
[MR16DDT ] A
EM
C
D
INSTALLATION Note the following, and install in the reverse order of removal. • Align marks. Attach each joint. Screw clamps firmly. • Fixing clips shall be fixed after inserting air cleaner body assembly protrusion to air cleaner case botch hole. • Make sure whether air cleaner body has been firmly installed by shaking it.
Inspection
E
INFOID:0000000006337251
F
INSPECTION AFTER REMOVAL Inspect air duct and resonator assembly for crack or tear. • If anything found, replace air duct and resonator assembly.
