OIL PAN (UPPER) < UNIT DISASSEMBLY AND ASSEMBLY > c. Press-fit the rear oil seal using a drift with outer diameter 113 mm (4.45 in) and inner diameter 90 mm (3.54 in) (commercial service tool) (A).
[HR16DE]
PBIC3660E
• Press-fit to the dimensions specified as shown in the figure.
d. 3.
1
: Rear oil seal
A
: Rear end surface of cylinder block
b
: 0 - 0.5 mm (0 - 0.020 in)
CAUTION: • Never touch the grease applied to the oil seal lip. • Be careful not to damage the rear oil seal mounting part of oil pan (upper) and cylinder block or the crankshaft. • Press-fit straight check that oil seal does not curl or tilt. After press-fitting the rear oil seal, completely wipe off any liquid gasket protruding to rear end surface side. Install in the reverse order of removal, for the rest of parts.
Inspection
INFOID:0000000006449934
INSPECTION AFTER INSTALLATION 1. 2. 3. 4.
PBIC3149J
Check engine oil level and adjust engine oil. Refer to LU-25, "Inspection". Check for leakage of engine oil when engine is warmed. Stop engine and wait for 10 minutes. Check engine oil level again. Refer to LU-25, "Inspection".
EM-226
