OIL PAN (LOWER) < REMOVAL AND INSTALLATION > b. Apply a continuous bead of liquid gasket (B) with a tube presser (commercial service tool) as shown in the figure. a
: 7.5 - 9.5 mm (0.295 - 0.374 in)
c
: φ4.0 - 5.0 mm (0.157 - 0.197 in)
1
: Oil pan (lower)
[HR16DE]
: Engine outside
Use Genuine Liquid Gasket or equivalent. CAUTION: Attaching should be done within 5 minutes after liquid gasket application.
JPBIA4746ZZ
c.
Tighten bolts in numerical order as shown in the figure. : Engine front
JPBIA4744ZZ
2.
3.
Install oil pan drain plug. • Refer to the figure of components of former page for installation direction of drain plug washer. Refer to EM-169, "Exploded View". Install in the reverse order of removal after this step. NOTE: Wait at last 30 minutes after oil pan (lower) is installed before pouring engine oil.
Inspection
INFOID:0000000006449907
INSPECTION AFTER REMOVAL Clean oil strainer if any object attached.
INSPECTION AFTER INSTALLATION 1. 2. 3. 4.
Check the engine oil level and adjust engine oil. Refer to LU-25, "Inspection". Start engine, and check there is no leakage of engine oil. Stop engine and wait for 10 minutes. Check the engine oil level again. Refer to LU-25, "Inspection".
EM-172
