OIL PAN (UPPER) < UNIT DISASSEMBLY AND ASSEMBLY > b. Apply engine oil to entire outside area of rear oil seal. c. Press-fit the rear oil seal using a suitable drift (A) with outer diameter 115 mm (4.53 in) and inner diameter 90 mm (3.54 in).
[MR16DDT ]
JPBIA4414ZZ
• Press-fit to the specified dimensions as shown in the figure.
3.
1
: Rear oil seal
A
: Cylinder block rear end surface
CAUTION: • Never touch the grease applied to the oil seal lip. • Be careful not to damage the rear oil seal mounting part of oil pan (upper) and cylinder block or the crankshaft. • Press-fit straight, checking that rear oil seal does not curl or tilt. NOTE: The standard surface of the dimension is the rear end surface of cylinder block. Install in the reverse order of removal, for the rest of parts.
Inspection
PBIC3952E
INFOID:0000000006337295
INSPECTION AFTER REMOVAL Clean oil strainer portion (part of the oil pump) if any object attached.
EM-102
