G170
LUBRICATION/FILTERS/FLUIDS TRANSMISSION Service Specifications Total system filling capacity with filters ................................................................ 25 liters (6.6 U.S. Gallons) Type of oil ............................................................................................................ See Fluids and Lubricants Oil level check interval .................................................................................................................... 10 hours Filter replacement interval .................................................................... After the first 100 hours of operation and then every 500 hours there after. Breather screen cleaning interval ................................................................................................ 1000 hours Oil change interval ............................................................................... After the first 100 hours of operation and then every 1000 hours there after. IMPORTANT: If the machine is new or the transmission has been replaced or rebuilt, change the transmission
oil and replace the filter after the first 100 hours of operation. IMPORTANT: Change the transmission oil and replace the filter after the first 100 hours of operation.
!
WARNING: Never drain oil or remove oil filter while engine is running.
Transmission Oil Level Check EACH 10 HOURS OR DAILY SERVICES Check the transmission oil level when the oil is hot and the system is charged. Place transmission in NEUTRAL, keep the engine idling and apply parking brake.
1
Turn the handle counterclockwise to loosen the cap. Remove the cap and check oil level with the dipstick. Add oil as necessary to bring it to the proper level. Make sure the cap is tight in the filler neck after checking oil. 1. TRANSMISSION OIL LEVEL DIPSTICK
Read the SAFETY RULES on the preceding pages for machine protection and the safety of employees
102
