Operation 1.20 Ventilation Windshield
WARNING! •
When opening the windshield, be sure to lock both latches. When closing the windshield, keep hands on handle and away from path of window.
1. The windshield can be opened for ventilation. Turn the latches (1), located at the upper corners of the windshield. See Fig. 17. Grasp the handle (2) and pull the windshield up until the latches lock in the open position. For additional ventilation, the lower portion of the windshield can be removed and securely stored in the glass holder (3) located on the rear window. 2. To close the windshield, reinstall the lower windshield and turn the latches; then lower the windshield and lock the latches in the closed position.
1
3
2
1
3
Fig. 17: Windshield locks
