Chapter 8 SERVICE AND STORAGE When a problem occurs, don’t overlook simple causes such as an empty fuel tank. Check for leaks and broken connections. Make note of any specific problem symptoms, noises, etc. and contact your local Mustang dealer.
GENERAL INFORMATION
WARNING BEFORE performing any service on the Telehandler, unless expressly instructed to the contrary, exercise the MANDATORY SAFETY SHUTDOWN PROCEDURE (Safety chapter). After service has been performed, BE SURE to restore all guards, shields and covers to their original positions BEFORE resuming machine operation.
IMPORTANT: Always dispose of waste lubricating oils, anti-freeze and hydraulic fluids according to local regulations or take them to a recycling center for disposal. DO NOT pour them onto the ground or into a drain.
DEALER SERVICES The following areas of internal components service replacement and operating adjustments should only be attempted by (or under the direction of) an authorized Mustang Telehandler dealer.
NOTE: All service routines, with the exception of those described under the “Dealer Services” topic, are owner-operator responsibilities. All operator services described under the subtopics are also referred to on a decal located inside the small rear access door of the operator’s station. Refer to the Lubrication chapter of this manual for lubrication information.
IMPORTANT: DO NOT service or repair major components, unless authorized to do so by your Mustang dealer. Any unauthorized repair will void the warranty.
POWERTRAIN COMPONENTS The engine and transmission are coupled together with a transfer case. All service routines related to the internal components are precise and critical to proper powertrain operation. The axle differential and planetary ends are also sophisticated assemblies that require special know-how and tools for servicing.
NOTE: This Service and Storage chapter details procedures to follow for making routine maintenance checks, adjustments and replacements. The majority of the procedures are also referred to in the Maintenance chapter of this manual. For engine-related adjustments and servicing procedures, refer to the engine manual provided.
IMPORTANT: If any area of powertrain componentry is suspected of faulty operation, contact your Mustang dealer for further assistance.
PRECAUTIONS
HYDRAULIC SYSTEM COMPONENTS
DO NOT perform any maintenance or repair without the owner’s prior authorization. Allow only trained personnel to service the machine.
Valves, pumps, motors and cylinders are sophisticated assemblies, which require special know-how and tools for servicing. All cylinders are approprietly designed with particular strokes, diameters, checks and hose connection provisions unique to the machine application requirements. A hydraulic schematic (located at the back of this manual) can be used as a guide for service reference, as required.
Warranty repairs can only be done by a Mustang dealer. Dealers know what portions of the machine are covered under the terms of the Mustang Warranty and what portions are covered by other vendor warranties.
