PBP_R
Service Manual
The multi-function display shows the following information: •
Level of battery charge
•
Indication of operational hours
•
System messages:
•
ECO = Economy mode selected
Lo SPd = Low speed mode selected
Fault codes:
•
Numeric code = warning or alarm. For more detailed information about warnings and alarms, see chapter 13.
LED indicator:
4.3.4
Flashing red = alarm
Driving position
A pallet truck equipped with a foldable operator’s platform can be driven either walking behind the truck (the pedestrian mode) or standing on the platform (the riding mode).
4.3.4.1 Pedestrian mode
Figure 9. Operator’s platform in the pedestrian mode
To drive the truck in the pedestrian mode, lift the operator’s platform up by lifting it slightly and allowing the gas spring to lift it up. To drive the truck in the direction of the forks, walk behind the truck and keep both hands on the tiller arm. To drive in the opposite direction, walk beside the truck and keep one hand on the tiller arm.
© Mitsubishi Forklift Trucks 2013. All rights reserved.
Revision: C
Document ID: 615026
24 (214)
